2-7FPC 5000 Front Panel Controller • FPC Installation and Operation

Power ( / )switch — Toggle the power switch to the on ( ) position. After

approximately 2 minutes, observe that the LCD touch panel displays the FPC

start-up screen (figure 2-8). See chapter 3, Matrix 12800 Operation, for using

the FPC to operate the Matrix 12800 system.

Figure 2-8 — FPC 5000 Start-up screen
